Reliable Performance:
ATS125A-4P automatic transfer switch helps the generator to smooth, reliable performance and long service life.
High Temperature Resistance:
The switch's exterior casing is composed of flame retardant material that is heat resistant, does not distort easily, and is safer to use.
Fast Switching:
This automatic transfer switch gives sensitive response, and fast switching of power supply. It can perform two-way power supply load transfer in under 80 milliseconds.
Noise-free Operation:
The Automatic Transfer Switch (ATS) gives the generator noise-free simple operation, convenient installation and stable performance.
Easy to Install:
It has rail-mounted installation, simple and convenient, effectively protect your electricity safety and stability.
Technical Specification:
| Model | ATS-125A-4P |
| Brand | Sakura, Powered By SmartGen |
| Rated Current | 125A |
| Rated Limited Short-Circuit Current | 35KA |
| Coil Operating Voltage | 220V |
| Coil Operating Current | 3.5A |
| Operation Cycle | 15 Seconds/time |
| Mechanical Operation Time | 10000 Times |
| Electrical Operation Time | 4000 Times |
| Net Weight | 5.5 KG |
| Country of Made |
China |
Warranty:
1 Year Warranty with parts and labor.
Installation Charge: Free (with Sakura Generator).
