Model

H 500

Brand

Hyundai

Engine Type

4-stroke, OHV, single-cylinder with forced air-cooled

Fuel Tank Capacity

6.5 Litre

Starting System

Recoil

Fuel Type:

Gasoline

Fuel Consumption/H

4 Litre (Depend on the Load)

Engine Oil Capacity

1 Litre

Country of Made:

China

Bore*stroke(mm):

94*72

Displacement(ml):

500

Compression ratio:

8.7:1

Max power output(kw/rpm):

12.5 kw/3600 rpm

Recommended power (kw/rpm):

11.5 kw/3600 rpm

HP

18 HP

Max torque(N.m/rpm):

31 N.m /2500 rpm

Ignition system:

Non-contact transistorized ignition(TCI)

Air cleaner:

Semi-dry type or oil bath type

Dry weight(kg):

32

Carton dimension(L*W*H mm):

450*405*440
