Technical Specification:
General Data:
| Model | SP55YD |
| Brand | Sakura |
| Continuous Power | 50 KVA |
| Continuous Power | 40 KW |
| Standby Power | 55 KVA |
| Standby Power | 44 KW |
| Volts | 220V / 380V |
| Frequency | 50HZ |
| Number of Phase | 3 |
| Engine RPM | 1500 |
| Power Factor | 0.8 |
Engine General Data:
| Engine Brand | Yangdong |
| Model | Y4102ZLD |
| Fuel | Diesel |
| Number of Cylinders | 4 |
| Fuel Tank Capacity | 70 L |
| Cooling System | Water Cooled |
Alternator General Data:
| Brand | Sakura |
| Type | Brushless |
| Model | SA224G55 |
| Th. Class | H |
| Protection | IP23 |
| AVR | SX460 |
Dimension and Noise Level:
| Length | 225 cm / 7.4 ft |
| Width | 85 cm / 2.8 ft |
| Height | 130 cm / 4.5 ft |
| Weight | 1130 KG |
| Sound From 7 mt | 69 dBA |
Fuel Consumption:
| 25% Load | 3.4 L/H |
| 50% Load | 5.7 L/H |
| 75% Load | 8.2 L/H |
| 100% Load | 10.7 L/H |
Useable applications: Whole building apartment, industrial power backup. lift, escalator, and others heavy-duty use
Engine: Yangdong Y4102ZD, water-cooled diesel engine super silent series world famous diesel engine
Power: Prime power 50 KVA/ 40KW standby power 55 KVA/ 44 KW
Alternator: SAKURA, IP23, H insulation class
Starting System: Electronic starting system
Fuel Type: Diesel
Noise level: In a distance of 7 miters operating noise level will be 69 dBA
Running Hours: 8 hours
Warranty:
Warranty Information:
1 Year Local Seller Warranty.
Installation Charge: Free.
Notes: Cable & other accessories costs will bear by the buyer.
