Technical Specification:
General Data:
| Model | WDG5000S |
| Brand | Sakura |
| Continuous Power | 5 KVA |
| Continuous Power | 5 KW |
| Standby Power | 5.5 KVA |
| Standby Power | 5.4 KW |
| Volts | 220V / 380V |
| Frequency | 50HZ |
| Number of Phase | 1 |
| Engine RPM | 3600 |
| Power Factor | 0.8 |
Engine General Data:
| Engine Brand | Sakura |
| Model | |
| Fuel | Diesel |
| Number of Cylinders | 4 |
| Fuel Tank Capacity | 15L |
| Cooling System | Air Cooled |
Alternator General Data:
| Brand | Sakura |
| Type | Brushless |
| Model | |
| TH. Class | H |
| Protection | IP23 |
| AVR | SX460 |
Dimension and Noise Level:
| Length | 36.1 inch |
| Width | 22.2 Inch |
| Height | 28.9 Inch |
| Weight | 175 KG |
| Sound From 7 mt | 67 dBA |
Fuel Consumption:
| 25% Load | 1.58 L/H |
| 50% Load | 1.2 L/H |
| 75% Load | |
| 100% Load |
Engine: Single cylinder, air-cooled, 4-stroke vertical engine Type, Less weight means better performance and better fuel efficiency. Air-cooled engines have fins which naturally dissipate the heat generated during the combustion stroke of the engine.
Power: Prime power 5 KVA Standby power 5.5 KVA
Alternator: 100% Copper alternator. Excitation current of aluminium wire AC alternator is larger, the voltage of output terminal of the alternator is higher, about 20-30V higher than copper one, a higher voltage will damage the usage life of the equipment.
Warranty:
Warranty Information:
1 Year Local Seller Warranty.
Installation Charge: Free.
Notes: Cable & other accessories costs will bear by the buyer.
