Technical Specification:
General Data:
| Model | SP66YD |
| Brand | Sakura |
| Continuous Power | 60 KVA |
| Continuous Power | 48 KW |
| Standby Power | 66 KVA |
| Standby Power | 52.8 KW |
| Volts | 220V / 380V |
| Frequency | 50HZ |
| Number of Phase | 3 |
| Engine RPM | 1500 |
| Power Factor | 0.8 |
Engine General Data:
| Engine Brand | Yangdong |
| Model | YD4EZLD |
| Fuel | Diesel |
| Number of Cylinders | 4 |
| Fuel Tank Capacity | 70 L |
| Cooling System | Water Cooled |
Alternator General Data:
| Brand | Sakura |
| Type | Brushless |
| Model | SA224G60 |
| Th. Class | H |
| Protection | IP23 |
| AVR | SX460 |
Dimension and Noise Level:
| Length | 254.9cm / 7.4ft |
| Width | 85cm / 2.8ft |
| Height | 190cm / 5ft |
| Weight | 1150 KG |
| Sound From 7 mt | 70 dBA |
Fuel Consumption:
| 25% Load | 7.2 L/H |
| 50% Load | 10.4 L/H |
| 75% Load | 13.9 L/H |
| 100% Load |
Useable applications: Utilities, telecom, hospital and data center, markets, as well as the industrial sectors equipment’s
Engine: Yangdong Y4105ZLD, water-cooled diesel engine
Power: Prime power 60 KVA, Standby power 66 KVA
Alternator: SAKURA, IP23, H insulation class
Starting System: Electronic starting system
Fuel Type: Diesel
Noise level: In the distance of 7 miter operating noise level will be 70 dBA
Running Hours: 8 hours
Warranty:
Warranty Information:
1 Year Local Seller Warranty.
Installation Charge: Free.
Notes: Cable & other accessories costs will bear by the buyer.
